Used Zoomlion Truck Crane Zoomlion ZTC950V Second Hand Truck Mobile Crane

Production Details:

This equipment is with 6 sections 63 meters oval main boom, 3-section 24.5-meter jib.

**Max. lifting height is 87.5m;

Industry classic gold transmission chain, strong power, mature and reliable, good passability; reserved space for 10t bottom counterweight and two truss arms (17.5m), which can be attached to the vehicle to reduce the cost of use;

standard reversing radar, main winch monitoring system, visual reversing image, safe and reliable.

This machine was manufactured in May 2019, traveled 1200 hours, 95 tons, 6-section boom truck crane, Euro 5 emission, original format original paint of the whole vehicle, no repairs, one set of counterweight, one-section jib, two hooks, including 60t and 6.5t.

Product Parameters:

Item		Value	Remarks
Working performance	Max. rated lifting capacity (Kg)	95000	3m range
	Max. load moment of the basic arm (KN.m)	4000	5m range
	Max. load moment of long main boom (KN.m)	1860	30m range
	Basic boom max. lifting height (m)	14
	Main boom max. lifting height (m)	64	The boom deformation is not considered, and the value in brackets is the value of the standard jib
	Jib max. lifting height (m)	80.5/ (87.5)
Working speeds	Max. hoist ropes peed (main winch) (m/min)	110	At fifth layer
	Max. hoist ropes peed (auxiliary winch) (m/min)	75	At third layer
	Boom derricking up time (s)	70
	Boom telescoping out time (min)	13
	Max. slewing speed (r/min)	1.5
Traveling parameters	Max. use altitude (m)	2000
	High travel speed (Km/h)	75
	Max. gradeability (%)	40
	Min. turning diameter (m)	23
	Min. ground clearance (mm)	300
	Limits for exhaust pollutants and smoke	Conform to related standards	GB3847-2005 GB17691-2005 (Euro V)
	Oil consumption per 100 km (L)	70
Weights	Deadweight in traveling condition (Kg)	54900	In the driving state, the jib, 25t hook, 7t auxiliary hook, auxiliary winch mechanism (including auxiliary coil wire rope) and movable counterweight of the crane cannot be driven with the vehicle and need to be disassembled; with arm tip pulley, 70t crane.
	Complete vehicle kerb mass (Kg)	54705
	Ⅰ, Ⅱ axle load (Kg)	9950/9950
	IV, V, VI axle load (Kg)	25100 (Dual axis) /9900
