Zoomlion ZCC750 Second Hand Crawler Cranes 75 Ton

Hunan Machine Home Information Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Zoomlion ZCC750 Second Hand Crawler Cranes 75 Ton from wholesalers

    Buy cheap Zoomlion ZCC750 Second Hand Crawler Cranes 75 Ton from wholesalers
    • Buy cheap Zoomlion ZCC750 Second Hand Crawler Cranes 75 Ton from wholesalers
    • Buy cheap Zoomlion ZCC750 Second Hand Crawler Cranes 75 Ton from wholesalers
    • Buy cheap Zoomlion ZCC750 Second Hand Crawler Cranes 75 Ton from wholesalers

    Zoomlion ZCC750 Second Hand Crawler Cranes 75 Ton

    Ask Lasest Price
    Brand Name : Zoomlion
    Model Number : ZCC750
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Delivery Time : 5-7 Days
    • Product Details
    • Company Profile

    Zoomlion ZCC750 Second Hand Crawler Cranes 75 Ton

    Used Zoomlion Crawler Crane Zoomlion ZCC750 Second Hand Crawler Crane

    Production Details:


    Model NO.

    ZCC750Boom TypeTower boom


    Max. Rated Lifting Capacity

    750000 kgMax. Lifting Height of Jib42m


    Max Gradeability

    30%Working hours1118H


    Transport Package

    Compliant with export packaging requirementsSpecification12800×3400×3250 MM


    Trademark

    ZoomlionPlace of OriginChina


    HS Code

    Supply Capacity1 Units Per Month

    • ZCC750 is a small tonnage series product of Zoomlion. This product has a main boom and a fixed jib, and the main boom with jib is added to improve the efficiency of switching conditions.
    • Product design, manufacturing, inspection and other processes are in full compliance with CE standards and strictly implemented to ensure the most perfect quality products provided to customers.
    • The domestic market share of products of the same model in the same industry is the first. It is widely used in lifting operations and hoisting work in industrial and mining enterprises, construction sites, power plants, ports, oil fields, warehouses, warehouses and stations.
    • The pictures on this product page are for reference only, please focus on the actual product.

    This product was manufactured in 2021, with more than 1,000 hours of use, complete accessories, 90% new, no task failure, factory warranty, excellent performance, welcome to inquire if you like it.

    Product Parameters:

    ItemValueRemarks
    Max. lifting weight × amplitude (t × m)75×3.5
    Self-weight when basic boom (t)62.5
    Main boom length (m)12~57
    Fixed arm length (m)6~18
    Fixed boom max. lifting capacity6.5
    Max. lifting capacity of main boom with jib30
    Fixed boom installation angle (°)10,30
    Main boom + fixed boom (m)42+18
    Reel single rope speedMain lift (m/min)120At fourth layer
    Auxiliary lift (m/min)120At fourth layer
    Amplitude (m/min)56At fourth layer
    Rotation speed (rpm)0~2.1
    Walking speed (km/h)0~1.6
    Gradeability (%)30
    Ground specific pressure (MPa)0.073
    Overall Dimensions L×W×H (mm)12800×3400×3250Including herringbone boom and bottom section boom
    EngineWeichaiRated power/speed (kW/rpm)175/2200
    Euro IIMaximum output torque/speed (Nm/rpm)1000/1400~1600
    Emission StandardsEU StageⅡ
    Cummins USARated power/speed (kW/rpm)153/1800
    Maximum output torque/speed (Nm/rpm)929/1300
    Emission StandardsTIER3
    Track gauge × ground length × track shoe width (mm)2600×5440×800Track frame retracted
    4200×5440×800Track frame extended
