Used Zoomlion Crawler Crane Zoomlion ZCC750V Second Hand Crawler Crane

Production Details:

• ZCC750 is a small tonnage series product of Zoomlion. This product has a main boom and a fixed jib, and the main boom with jib is added to improve the efficiency of switching conditions.
• Product design, manufacturing, inspection and other processes are in full compliance with CE standards and strictly implemented to ensure the most perfect quality products provided to customers. The domestic market share of products of the same model in the same industry is the first.
• It is widely used in lifting operations and hoisting work in industrial and mining enterprises, construction sites, power plants, ports, wharfs, oil fields, warehouses, warehouses, etc.
• The pictures on this product page are for reference only, please focus on the actual product.

This product was manufactured in 2013, with more than 8,000 hours of use, complete accessories, no task failures, and excellent performance. Welcome to inquire if you like it.

Product Parameters:

Specifications				Unit	Value
Max. lifting weight × amplitude (t × m)				75×3.5
Self-weight at basic boom (t)				62.5
Main boom length (m)				12~57
Fixed boom length (m)				6～18
Fixed boom Max. lifting capacity				6.5
Max. lifting capacity of main boom with jib				30
Fixed boom installation angle (°)				10,30
Main boom + fixed boom (m)				42＋18
Reel single rope speed		Main lift (m/min)		120	Reel fourth layer
		Auxiliary hoist (m/min)		120	Reel fourth layer
		Amplitude (m/min)		56	Reel fourth layer
Rotation speed (rpm)				0～2.1
Walking speed (km/h)				0～1.6
Gradeability (%)				30
Ground specific pressure (MPa)				0.073
Overall Dimensions L×W×H (mm)				12800×3400×3250	Including herringbone boom and bottom section boom
Engine	Weichai		Rated power/speed (kW/rpm)	175/2200
	Euro II		Max. output torque/speed (Nm/rpm)	1000/1400～1600
			Emission Standards	EU StageⅡ
	Cummins USA		Rated power/speed (kW/rpm)	153/1800
			Max. output torque/speed (Nm/rpm)	929/1300
			Emission Standards	TIER3
Track gauge × ground length × track shoe width (mm)				2600×5440×800	Track frame retracted
				4200×5440×800	Track frame extended
